Rockford Fosgate Punch P1S2-10 / P1S4-10 10 inch subwoofer

€129.00

Rockford Fosgate Punch P1S2-10 / P1S4-10



Sale info

  • Condition: New
  • Sale type: BTW/21%
  • Stock : 2 -4 days extra delivery time

Productinfo:

  • 10" (25cm) Subwoofer
  • Load capacity RMS 250 Watts
  • Load capacity Max 500 Watts
  • Diameter of the vibrating coil: 51.6 mm
  • Weight of the magnet: 1.28 kg
  • Installation depth: 135.4 mm
  • Cut-out diameter: 232 mm
  • Displacement of the subwoofer: 1.6 liters
  • Shipping weight: 5.03 kg
  • Available in single 2-ohm and single 4-ohm impedance
  • 2 Ohm Variant:
    • Nominal impedance: 2 Ohm
    • Swing coil type: single swing coil
    • Fs (Hz): 30
    • Qms: 2.70
    • Xmax (mm): 9.0
    • Re (Ohm): 1.60
    • Qts: 0.52
    • Low: 0.75
    • Vas (Liter): 35.4
    • Le (mH):
    • Sd (cm2): 370
    • SPL (dB @ 1w/1m): 85
    • SPL (dB @ 2.8v/1m): 88
    • Closed enclosure volume (Vb): 16.7 liters
    • Bass reflex enclosure volume (Vb): 39.6 liters
  • 4 Ohm Variant:
    • Nominal impedance: 4 Ohm
    • Swing coil type: Single swing coil
    • Fs (Hz): 30
    • Qts: 0.52
    • Low: 0.61
    • Qms: 3.00
    • Vas (Liter): 40
    • Re (Ohm): 3.6
    • Xmax (mm): 9.0
    • The (mH): 2.81
    • Sd (cm2): 370
    • SPL (dB @ 1w/1m): 85
    • SPL (dB @ 2.8v/1m): 88
    • Closed enclosure volume (Vb): 16.7 liters
    • Bass reflex enclosure volume (Vb): 39.6 liters
