Rockford Fosgate Punch PM400X4 4 channel amplifier Marine

Rockford Fosgate Punch PM400X4 4 channel amplifier Marine
€499.00

Rockford Fosgate Punch PM400X4 Marine



Sale info

  • Condition: New
  • Sale type: BTW/21%
  • Stock : 2 -4 days extra delivery time

Technical Features

  • High-level capable input with auto turn-on circuit
  • Features of C.L.E.A.N. Attitude
  • 12dB/Octave Butterworth Crossover
  • Built-in punch EQ with +18dB boost at 45Hz
  • Damped Switching
  • Cast aluminum heat sink
  • Stealth control panel on the top
  • short-circuit protection
  • Overcurrent protection
  • Hardware made of marine-grade stainless steel
  • Two-component epoxy coating of circuit boards in marine quality

Specifications

  • Number of channels 4
  • Total power (sum of rated power) 400 watts
  • Rated power (RMS continuous power)
  • 50 Watt x 4 @ 4-Ohm
  • 100 Watt x 4 @ 2-Ohm
  • 200 Watts x 2 @ 4-Ohm bridged
  • Dynamic Performance (PVC/PowerCube®)
  • 82 Watt x 4 @ 4-Ohm
  • 137 Watt x 4 @ 2-Ohm
  • 266 Watts x 2 @ 4-Ohm bridged
  • Bridgable Yes
  • Frequency response 20Hz to 20kHz +/- 1.0dB
  • Input sensitivity 150 mV - 12 V
  • Class A/B Circuit Topology
  • Efficiency (average) 67% @ 4-Ohm
  • Total Harmonic Distortion (THD+Noise)
  • 4-Ohm: <1.0%
  • 2-Ohm: <1.0%
  • Signal input high/low level: 2 RCA pairs
  • Sound controller Front Punch EQ2 Bass: 0dB to +18dB at 45Hz and/or
  • Front Punch EQ2 Treble: 0dB to +12dB @ 12.5kHz
  • Rear Punch EQ2 Bass: 0 dB to +18 dB at 45 Hz and/or
  • Rear Punch EQ2 Treble: 0dB to +12dB @ 12.5kHz
  • Function depends on the position of the LP/AP/HP switch.
  • Crossover Controller Front High Pass/Low Pass (HP/LP): 50Hz-250Hz @ 12dB/Octave Butterworth
  • Rear High-pass/Low-pass (HP/LP): 50Hz-250Hz @ 12dB/Octave Butterworth
  • All-Pass: Yes
  • Optical Indicators Power/Protect/Thermal LED
  • Input Clip LED 3
  • Output Clip LED 1,2,3
  • LED Color Legend:
  • 1BLAU: <0.5% THD
  • 2VIOLETT: 1% THD
  • 3ROT: 10%+ THD
  • Power connections 10mm² - 25mm²
  • Network input connection fixed C-clamp
  • Speaker cable cross-section 1mm²-10mm²
  • Speaker output connection captive C-clamp
  • heat sink
  • Operating voltage 9 - 16 VDC
  • Recommended fuse (not included) 60 A
  • Average current consumption (13.8 V music) 30 A
  • Max. current consumption (13.8 V sine wave) 60 A
  • Recommended alternator 75 A
  • Dimensions (H x W x D) 6.05 x 19.71 x 28.02 (cm)
