Delta Elektronika SM300-20 300V DC powersupply
Sold out
€1,649.00
Delta Elektronika SM300-20
- Condition: used( tested / inspected )
- sale type: margin
- Stock : shipped within 24 hours
Productinfo:
- SM300-20 / SM6000 SERIES
- 0-300V DC / 0-20A DC
- Input voltage (3 phase, rated voltage range): 342 - 528 VAC, Vnom line to line (48-62 Hz)
- Active Power Factor Correction (PFC): 0.98 (at 100% load)
- Efficiency: up to 90% (at full load)
- Output ripple and spikes: from 0.8 mVRMS / 10 mVPP
- Regulation: from 2.5 mV (0-100% load step)
- Recovery time: from 100 μs (50-100% load step)
- Programming speed: from 2.7 ms (10-90%), optional from 0.4 ms
- Analog programming accuracy: from 0.2%
- Output voltage and current stability: 5.10-5 / 10.10-5
- MTBF: 500 000 hrs
- Operating ambient temperature: -20 to +50 °C
- 19'' 4U
- 542mm depth
- Every used product is tested again before shipment. ( send a whatsapp message if you want to receive a test video)
