Rockford Fosgate Prime R2-750X5 5 channel amplifier

Rockford Fosgate Prime R2-750X5 5 channel amplifier
€499.00

Rockford Fosgate Prime R2-750X5



  • Condition: New
  • Sale type: BTW/21%
  • Warranty: Factory warranty
  • Stock : 2 -4 days extra delivery time

Productinfo:

  • Balanced differential inputs with RCA pass-through outputs.
  • High level input suitable
  • 2/4/5-channel input selector switch
  • Auto-sense bypass switch for vehicles with RAP (Retained Accessory Power)
  • Features C.L.E.A.N. setting
  • RLC level remote control included
  • Variable infrasonic filter
  • Continuously variable on-board punch EQ
  • Front, Rear and Sub Variable Input Gain Adjustment
  • Top mounted control panel
  • Short circuit and over current protection
  • CEA-2006 compliant & CE compliant
  • Cast aluminum heat sink
  • Full range Class-D
  • Rollback protection
  • Fully adjustable 12 dB/octave high-pass and low-pass Butterworth crossovers

Specifications:

  • 5-channel amplifier
  • RMS power:
    • 50 watts x 4 + 200 watts x 1 @ 4Ω
    • 100 Watt x 4 + 350 Watt x 1 @ 2Ω
    • 200 Watts x 2 + N/A @ 4Ω Bridging/Mono
  • Dynamic power
    • 70 Watts x 4 + 241 Watts x 1 @ 4Ω
    • 114 Watt x 4 + 426 Watt x 1 @ 2Ω
    • 234 Watts x 2 + N/A @ 4Ω Bridging/Mono
  • Bridgeable : Yes
  • Frequency response : 20 Hz - 20 kHz
  • Input sensitivity : Low level: 150 mV - 4 V
  • High level : 450 mV - 12 V
  • Circuit topology class : Class-D
  • Signal input : Front low level: 2 RCA
  • Front High-Level: 4-Pin Molex
  • Rear Low-Level: 2 RCA
  • Rear high level: 4-pin Molex
  • Sub low level: 2 RCA
  • Sub high level: 4 pin Molex
  • Input switch: 2/4/5 inputs (works for RCA/Hi level inputs)
  • Tone control: 0 to +18 dB at 45 Hz
  • Front high pass: 50 Hz - 250 Hz @ 12dB/octave Butterworth
  • Front low pass: 50 Hz - 250 Hz @ 12dB/octave Butterworth
  • Rear high pass: 50 Hz - 250 Hz @ 12dB/octave Butterworth
  • Rear low pass: 50 Hz - 250 Hz @ 12dB/octave Butterworth
  • Sub Low Pass: 50 Hz - 250 Hz @ 12dB/octave Butterworth
  • Sub Infrasonic: 15 Hz - 40 Hz @ 12dB/octave Butterworth
  • Remote controls : Yes
  • Cable diameter : 20mm²
  • Loudspeaker cable diameter : 8mm²
  • Cooling : Convection
  • Operating voltage : 9 - 16 VDC
  • Recommended fuse 120 A
  • Max. Current consumption (13.8 V sine) : 71 A
  • Dimensions (H x W x D) : 4.9 cm x 17.3 cm x 28.5 cm
