MOSCONI AERO8|12DSP 12 channel DSP

€1,149.00

MOSCONI AERO8|12DSP 12 channel DSP



Sale info

  • Condition: New
  • Sale type: BTW/21%
  • Stock : 2 -4 days extra delivery time

Productinfo:

  • 8 x RCA (Cinch), switchable High / Low Level with Autosense
  • 4 of them freely selectable as prioritized auto-fade / Aux
  • 1 x S/PDIF digital optical
  • 1 x RCA digital COAX
  • 1 x BT slot
  • ATOM Mixer menu with dynamic preset switching and "Trigger" control

Exits

  • 12 x RCA analog
  • 1 x S/PDIF optical (freely assignable, volume controlled)
  • 12 V Remote-out

Equalizer

  • Fully parametric 30 band EQ, also usable graphically, + 12 to - 12 dB, Q: 0.5 - 40
  • Fixed sorted: Front channels (1 – 6) Rear channels (9 + 10)
  • Assignable channels: 7 + 8 = Front, Rear 11 + 12 = Sub, Center, Free

Filter

  • 10 channels freely configurable, (setting without audio interruption)
  • High-pass, Low-pass, Shelf, Notch, All-pass, Peak-EQ
  • Slope steepness 6 – 120 dB/octave, variable Q, time and level

Miscellaneous

  • Compatible with BARNIE calibration system
  • Runtime correction 0 – 12 ms (0.005 ms steps) (setting without sound interruption)
  • Input Delay (Channels 1 – 6) for the correction of time-delayed production systems
  • Phase shift 0 - 180°
  • Level adjustment outputs (0.5 dB steps)
  • Mute function
  • 4 x Preset Memory (Switching without audio interruption)
  • Dimensions 200 x 125 x 40 mm (including mounting flange)
