MOSCONI PICO 4|8 DSP Amplifier

MOSCONI PICO 4|8 DSP Amplifier
€599.00

MOSCONI PICO 4|8 DSP Amplifier



Sale info

  • Condition: New
  • Sale type: BTW/21%
  • Stock : 2 -4 days extra delivery time

Productinfo:

  • 4 x Analog inputs symmetrical (High-Level) up to 30 V
  • 2 x switchable analog inputs (High-Level / Low-Level)
  • 1 x Digital input SP-Dif optical (8 kHz – 96 kHz Sampling rate)
  • 1 x Bluetooth port with SP-Dif – TTL (8 kHz – 96 kHz, e.g. for Mos_BTS Bluetooth streaming module)
  • Bluetooth Extended Digital Audio Port (BT+) (flexible 8 kHz – 384 kHz synchronous digital input for audio sources with 2 – 16 channels, direct DSP access without jitter, e.g. for MOS BTS-LD4C BT streaming module or extended analog inputs)

DSP part

  • 912 MHz, 32-Bit Audio-Port, 64-Bit Core
  • Double Precision 56 Bit Filter Calculation
  • 6144 SIMD instructions per sample at 48 kHz ASRCs from 1:8 to 7.75:1 ratio and 139 dB DNR

control

  • 1 x Remote Connector (Analog, for RTC.2 Potentiometer Remote Control)
  • 1 x Bluetooth control port (connection MOS-BT3.0 (app control), RC-Can (CAN bus control), MOS_USB2.0 (programming dongle)
  • 1 x Remote Out, 1 x Remote In, Auto-Remote with high-level connection
  • Connections with MOLEX® connectors
  • Very small construction size with low heat generation, ideally suited for installation behind coverings.

Software

  • 3 x 9 band parametric input EQ (De-Equalizing)
  • 6 x Input Delay 0 – 3 ms / 0.01 ms (De-Delay)
  • 10 x Input Level Controllers digital (Signal Conditioning)
  • Flexible mixer for signal routing (side-separated, can sum and subtract, 10 inputs to 4 x 2 output groups)
  • 6 x 30 band or 4 x 30 band + 2 x 15 band group EQ (parametric, relative phase remains stable)
  • 8 x 10 band output filter
  • HighPass / LowPass / HighShelf / LowShelf / Notch / Allpass 1st + 2nd Order / Speaker-EQ)
  • 8 x Speaker-Delay 0 – 12 ms, 0.02 ms
  • 8 x Speaker Phase switch

Technical Data

output power

  • Output power at 4 Ohms: 4 x 90 Watts
  • Output power at 2 Ohms: 4 x 115 Watts
  • Output power at 4 Ohms: 2 x 85 Watts + 1 x 230 Watts (bridged)
  • Output power at 4 Ohms: 2 x 230 Watts (bridged)
  • Line Out: 4 x 2 Vrms Line Out

Data

  • Input voltage: 0.3 - 15 V
  • Efficiency above all: > 80 %
  • Auto-On (only High Level): Off - BTL
  • Dimensions: 150 x 133 x 46 mm
